PLATE
Ref. No. | DESCRIPTION | PART NO. |  |  |  |  |  |  |  |  |  |  | REMARKS |
| Gearbox Assembly, 5-Speed | A083F6000F | | | * | * | * | | 1 | | | | |
| Setscrew, M12 x 45, Gearbox/Clutch Housing | A075W1061Z | | | * | * | * | | 4 | | | | Replaces Studs & Nuts |
| Washer, 12 mm, Gearbox/Clutch Housing | A075W4071Z | | | * | * | * | | 4 | | | | |
| Front Cover Assembly | A083F6087F | | | * | * | * | | 1 | | | | Includes Guide Tube & S |
| Oil Seal, Front Cover | A083F6088F | | | * | * | * | | 1 | | | | |
| Gasket, Front Cover | A083F6089F | | | * | * | * | | 1 | | | | |
| Bolt, M8 x 30, Front Cover | A075W2037Z | | | * | * | * | | 3 | | | | |
| Bolt, M8 x 22, Front Cover | A083F6090F | | | * | * | * | | 4 | | | | |
| Washer, Wavy, 8 mm Front Cover | A083F6094F | | | * | * | * | | 7 | | | | |
| Shim, 0.1 mm, Input Shaft Bearing | A083F6095F | | | * | * | * | | AR | | | | |
| Shim, 0.3 mm, Input Shaft Bearing | A083F6096F | | | * | * | * | | AR | | | | |
| Shim, 0.1 ram, Layshaft Front Bearing | A083F6097F | | | * | * | * | | AR | | | | |
| Shim, 0.3 mm, Layshaft Front Bearing | A083F6098F | | | * | * | * | | AR | | | | |
| Bush, Selector Shaft | A083F6115F | | | * | * | * | | 2 | | | | |
| Tailshaft Bush | A083F6116F | | | * | * | * | | 1 | | | | |
| Oil Seal, Tailshaft | A083F6118F | | | * | * | * | | 1 | | | | |
| Speedo Driven Gear (18T) | A083F6120F | | | * | * | * | | 1 | | | | |
| Bush, Speedo Driven Gear | A083F6121F | | | * | * | * | | 1 | | | | |
| 'O' Ring, Speedo Driven Gear Bush | A083F6122F | | | * | * | * | | 1 | | | | |
| Oil Seal, Speedo Gear Spindle | A083F6123F | | | * | * | * | | 1 | | | | |
| Right Angle Drive, Speedo (for 4.1 Final Drive) | A083F0393F | | | * | * | * | | 1 | | | | Stamped 1.384 |
| Right Angle Drive, Speedo (for 3.73 Final Drive) | A083F0392F | | | * | * | * | | 1 | | | | Stamped 1.266 |
| Retaining Plate, Speedo Gear Bush | A083F6124F | | | * | * | * | | 1 | | | | |
| Screw, M6 x 15, Retaining Plate | A083F6125F | | | * | * | * | | 1 | | | | |
| Washer, 6 mm | A0B3F6126F | | | * | * | * | | 1 | | | | |
| Switch, Reverse Light | A083F6127F | | | * | * | * | | 1 | | | | |
| Sealing Ring, Reverse Switch | A083F6128F | | | * | * | * | | 1 | | | | |
| Valve, Breather | A083F6129F | | | * | * | * | | 1 | | | | |
| Plug, Oil Level | A083F6130F | | | * | * | * | | 1 | | | | |
| Plug, Oil Drain (magnetic) | A083F6131F | | | * | * | * | | 1 | | | | |
