Esprit S1, S2, S2.2 PARTS MANUAL

Section VE -- Trim -- Boot Trim


PLATE
Ref. No.
DESCRIPTION
PART NO.
REMARKS
Board, Boot, Front, FloorC079LM141F 22 When Battery is by Window
Board, Boot, Front, FloorD079U4141F 22 When Battery is in Boot Floor
Board, Boot, Front, FloorB079U4417F 2When Battery is by Window
Board, Boot, Front, FloorA079U4472F 2When Battery is in Boot Floor
Board, Boot, Rear, FloorB079U4143F 2 When Battery is by Window
Board, Boot, Rear, FloorC079U4143F 2 When Battery is in Boot Floor
Board, Boot, Side, RHD079U4414F 1
Board, Boot, Side, LHB079U4477F 1
Board, Boot, Rear, VerticalD079LM142F 22
Board, Boot, Rear, VerticalC079U4416F 2
Angle, Rear Board LocationA079U4145K 4
Panel, Battery Cover ( Window Sill)A079U4330F 2 When Battery is by Window
Panel, Battery CoverA079U4468K 1 When Battery is in Boot Floor
Tonneau CoverB079V4183K 1
Button, Cover FixingA076W6109D 6
Socket, Cover FixingA076W6110D 6
Stud, Cover FixingA076W6111D 6
Support Bracket, Floor BoardA079U4151K 4 When Battery is by Window
Bracket, Floor Board to BulkheadB079V4147K 4 When Battery is by Window
Support Bracket, Floor BoardA079U4473F 4 When Battery is in Boot Floor
Bracket Floor Board to BulkheadA079U4474F 2 When Battery is in Boot Floor
Bracket, Floor Board to Wheel ArchA079U4475F 2 When Battery is in Boot Floar
Stud PlateA079U4482F 4
Carpet, Boot Floor, Fwd, RHA079V4238K 1 When Battery is by Window
Carpet, Boot Floor, Fwd, RHB079V4238K 1 When Battery is in Boot FI oar
Carpet, Boot Floor, Fwd, LHA079V4239K 1 When Battery ;s by Window
Carpet, Boot Floor, Fwd, LHB079V4239K 1 When Battery is in Boot Floor
Carpet, Boat Floor, RearA079V4243K 11
Carpet, Boot Floor, RearA079V4240K 1
Carpet, Rear Wheel Arch, LHA079V4241K 1
Carpet, Rear Wheel Arch, RHA079V4242K 1
Carpet, Rear jr Window Sill, RHA079V4244K 1
Carpet, Rear jr Window Sill, LHA079V4245K 1
