 |  |  |  |  |  |  |  |  |  | Notes Bulletin Reference | |||
| 026B0707 | 1 | 1 | Door Assembly, LH | Upto 5810 | |||||||||
| 026B0708 | 1 | 1 | Door Assembly, RH | Upto 5810 | |||||||||
| 1 | A026B0755 | 1 | 1 | Door Shell, LH | Upto 5810 | ||||||||
| A026B0756 | 1 | 1 | Door Shell, RH | Upto 5810 | |||||||||
| 2 | A026B0751 | 1 | 1 | Guide Channel, Rear, LH | Upto 5810 | ||||||||
| A026B0752 | 1 | 1 | Guide Channel, Rear, RH | Upto 5810 | |||||||||
| 026B6062 | 1 | 1 | Glazing Channel | Upto 5810 | |||||||||
| 026B0391 | 4 | 4 | Pad, Channel | Upto 5810 | |||||||||
| 3 | A026B0099 | 1 | 1 | Mounting Channel, LH | Upto 5810 | ||||||||
| A026B0100 | 1 | 1 | Mounting Channel, RH | Upto 5810 | |||||||||
| 026B6019 | 2 | 2 | Glazing Channel | Upto 5810 | |||||||||
| 026B0406 | 2 | 2 | Spring, Window Lock | Upto 5810 | |||||||||
| 026B0407 | 1 | 1 | Window Lock Arm, LH | Upto 5810 | |||||||||
| 026B0408 | 1 | 1 | Window Lock Arm, RH | Upto 5810 | |||||||||
| 026B0392 | 2 | 2 | Pivot Pin, Window Lock | Upto 5810 | |||||||||
| A02W0405 | 2 | 2 | Washer, Window Lock | Upto 5810 | |||||||||
| 026B0394 | 2 | 2 | Knob, Window Lock | Upto 5810 | |||||||||
| 026B0390 | 2 | 2 | Rod, Window Lock | Upto 5810 | |||||||||
| LUCN080F | 2 | 2 | Nut, Window Lock | Upto 5810 | |||||||||
| 4 | 026B0745 | 1 | 1 | Guide Channel, Front, LH | Upto 5810 | ||||||||
| 026B0746 | 1 | 1 | Guide Channel, Front, RH | Upto 5810 | |||||||||
| 026B045 | 1 | 1 | Window Guide Channel | Upto 5810 | |||||||||
| 026B0559 | 6 | 6 | Packing Piece | Upto 5810 | |||||||||
| 026B6020 | 2 | 2 | Glazing Channel | Upto 5810 | |||||||||
| 5 | 026B0101 | 2 | 2 | Sealing Strip, Front Guide | Upto 5810 | ||||||||
| KUCS0412 | 8 | 8 | Screw, Channels to Door | Upto 5810 | |||||||||
| L04W0000 | 8 | 8 | Lockwasher, Channels to Door | Upto 5810 | |||||||||
| A04W0905 | 8 | 8 | Washer, Channels to Door | Upto 5810 | |||||||||
| 026B0093 | AR | AR | Shim, Front Channel Mounting | Upto 5810 | |||||||||
| 026B0094 | AR | AR | Shim, Front Channel Mounting | Upto 5810 | |||||||||
| 6 | 026B0747 | 2 | 2 | Counterbalance Assembly | Upto 5810 | ||||||||
| 026B0112 | 2 | 2 | Window 'Up' Stop | Upto 5810 | |||||||||
| XUFS0208 | 2 | 2 | Screw, Stop | Upto 5810 | |||||||||
| A026B0114 | 2 | 2 | Window 'Down' Stop | Upto 5810 | |||||||||
| KSTS0412 | 4 | 4 | Screw, Stop | Upto 5810 | |||||||||
| 026B6021 | 4 | 4 | Lifting Stud | Upto 5810 | |||||||||
| A10W1909 | 4 | 4 | Washer | Upto 5810 | |||||||||
| 026B0110 | 2 | 2 | Mounting Plate | Upto 5810 | |||||||||
| 026B6022 | 2 | 2 | Washer | Upto 5810 | |||||||||
| 026B6044 | 2 | 2 | Washer | Upto 5810 | |||||||||
| 7 | 026B0111 | 2 | 2 | Spring | Upto 5810 | ||||||||
| 8 | 026B0113 | 2 | 2 | Sleeve | Upto 5810 | ||||||||
| 026B0091 | 2 | 2 | Liftlng Channel | Upto 5810 | |||||||||
| XUCS0412 | 4 | 4 | Screw, Liftlng Channel | Upto 5810 | |||||||||
| A04W0905 | 4 | 4 | Washer, Liftlng Channel | Upto 5810 | |||||||||
| L04WC000 | 4 | 4 | Lockwasher, Liftlng Channel | Upto 5810 | |||||||||
| 9 | 026B0090 | 2 | 2 | Glass, Door | Upto 5810 | ||||||||
| 10 | A026B0092 | 2 | 2 | Finger Lift | Upto 5810 | ||||||||
| A026B0393 | 2 | 2 | Backing Plate, Finger Lift | Upto 5810 | |||||||||
| 026B0719A | 1 | 1 | Door Trim Assembly, LH | Upto 5810 | |||||||||
| 026B0720A | 1 | 1 | Door Trim Assembly, RH | Upto 5810 | |||||||||
| 11 | A026B0721A | 1 | 1 | Door Trim Panel, LH | Upto 5810 | ||||||||
| A026B0722A | 1 | 1 | Door Trim Panel, RH | Upto 5810 | |||||||||
| A026B0221 | 2 | 2 | Plate, Armrest | Upto 5810 | |||||||||
| A026B0222 | 2 | 2 | Backing Strip | Upto 5810 | |||||||||
| 026B6000 | 10 | 10 | 'Pop' Rivet | Upto 5810 | |||||||||
| KSTS0416 | 6 | 6 | Screw, Trim Panel | Upto 5810 | |||||||||
| KSTS0410 | 2 | 2 | Screw | Upto 5810 | |||||||||
| A026B0054 | 4 | 4 | Spacer | Upto 5810 | |||||||||
| 026B0245 | 1 | 1 | Strip, LH | Upto 5810 | |||||||||
| 026B0244 | 1 | 1 | Strip, RH | Upto 5810 | |||||||||
| 026B6045 | 4 | 4 | Weatherstrip | Upto 5810 | |||||||||
| 026B6046 | 20 | 20 | Clip | Upto 5810 | |||||||||
| 026B0247 | 1 | 1 | Channel, LH, Weatherstrip Mounting | Upto 5810 | |||||||||
| 026B0246 | 1 | 1 | Channel, RH, Weatherstrip Mounting | Upto 5810 | |||||||||
| 026B0252 | 2 | 2 | Clamp, Weatherstrip Mounting | Upto 5810 | |||||||||
| KUFS0816 | 2 | 2 | Screw, Weatherstrip Mounting | Upto 5810 | |||||||||
| 036B6002 | 2 | 2 | Nut, Weatherstrip Mounting | Upto 5810 | |||||||||
| KSTS0408 | 2 | 2 | Screw, Weatherstrip Mounting | Upto 5810 | |||||||||
| 12 | B026B0723A | 1 | 1 | Armrest Trim Panel, LH | Upto 5810 | ||||||||
| B026B0724A | 1 | 1 | Armrest Trim Panel, RH | Upto 5810 | |||||||||
| XUFS0416 | 10 | 10 | Screw, Armrest | Upto 5810 | |||||||||
| LUFN040F | 10 | 10 | Nut, Armrest | Upto 5810 | |||||||||
| 026B6047 | 10 | 10 | Cupwasher, Armrest | Upto 5810 | |||||||||
| KSTS0410 | 2 | 2 | Screw, Armrest | Upto 5810 | |||||||||
| 026B0211 | 1 | 1 | Trim Extension, LH | Upto 5810 | |||||||||
| 026B0212 | 1 | 1 | Trim Extension, RH | Upto 5810 | |||||||||
| KSTS0410 | 2 | 2 | Screw, Trim to Extension | Upto 5810 | |||||||||
| KSTS0812 | 4 | 4 | Screw, Extenslon to Armrest | Upto 5810 | |||||||||
| 026B6050 | 4 | 4 | Nut | Upto 5810 | |||||||||
| 026B6048 | 1 | 1 | Ashtray | Upto 5810 | |||||||||
| 026B6049 | 2 | 2 | Door Pull | Upto 5810 | |||||||||
| KSTS0816 | 4 | 4 | Screw, Door Pull | Upto 5810 |
