 |  |  |  |  |  |  |  |  |  | Notes Bulletin Reference | |||
| 1 | 026B0119 | 1 | 1 | 1 | 1 | 1 | Headlamp Bowl, LH | Non-Failsafe | |||||
| 2 | 026B0120 | 1 | 1 | 1 | 1 | 1 | Headlamp Bowl, RH | Non-Failsafe | |||||
| XUCS0420 | 2 | 2 | 2 | 2 | 2 | Screw | Non-Failsafe | ||||||
| 3 | 026B0119A | 1 | Headlamp Bowl, LH | 1970 Fedaral Failsafe | |||||||||
| 4 | 026B0120A | 1 | Headlamp Bowl, RH | 1970 Fedaral Failsafe | |||||||||
| XUCS0432 | 2 | Screw | 1970 Fedaral Failsafe | ||||||||||
| L04W0000 | 2 | Washer | 1970 Fedaral Failsafe | ||||||||||
| 5 | 026B0123 | 1 | 1 | 1 | 1 | 1 | Vacuum Cylinder, LH | Non-Failsafe | |||||
| 6 | 026B0124 | 1 | 1 | 1 | 1 | 1 | Vacuum Cylinder, RH | Non-Failsafe | |||||
| XUFS0412 | 2 | 2 | 2 | 2 | 2 | Screw, Cylinders to Body | Non-Failsafe | ||||||
| YUFN040F | 4 | 4 | 4 | 4 | 4 | Nut, Cylinders to Body | Non-Failsafe | ||||||
| A04W0904 | 2 | 2 | 2 | 2 | 2 | Washer, Cylinders to Body | Non-Failsafe | ||||||
| A04W1606 | 2 | 2 | 2 | 2 | 2 | Washer, Cylinders to Body | Non-Failsafe | ||||||
| 7 | 036B1664 | 1 | Vacuum Cylinder | 1970 Fedaral Failsafe | |||||||||
| LUFN 040F | 1 | Nut, Cylinder to Bracket | 1970 Fedaral Failsafe | ||||||||||
| A04W0904 | 1 | Washer, Cylinder to Bracket | 1970 Fedaral Failsafe | ||||||||||
| 8 | 036B1829 | 2 | 2 | 2 | 2 | 2 | Bracket, Vacuum Cylinder | Non-Failsafe | |||||
| XUFS0408 | 4 | 4 | 4 | 4 | 4 | Screw, Bracket to Body | Non-Failsafe | ||||||
| LUFN040F | 4 | 4 | 4 | 4 | 4 | Nut, Bracket to Body | Non-Failsafe | ||||||
| A04W1606 | 4 | 4 | 4 | 4 | 4 | Washer, Bracket to Body | Non-Failsafe | ||||||
| 9 | 036B1315 | 1 | Bracket, Vacuum Cylinder | 1970 Fedaral Failsafe | |||||||||
| XUFS0408 | 3 | Screw, Bracket to Body | 1970 Fedaral Failsafe | ||||||||||
| LUFN040F | 3 | Nut, Bracket to Body | 1970 Fedaral Failsafe | ||||||||||
| A04W1606 | 3 | Washer, Bracket to Body | 1970 Fedaral Failsafe | ||||||||||
| 10 | 026B0117 | 1 | 1 | 1 | 1 | 1 | Spring, Headlamp Return, LH | Non-Failsafe | |||||
| 11 | 026B0118 | 1 | 1 | 1 | 1 | 1 | Spring, Headlamp Return, RH | Non-Failsafe | |||||
| 12 | XUFB0420 | 2 | 2 | 2 | 2 | 2 | Bolt, Return Spring to Headlamp | Non-Failsafe | |||||
| 13 | 026B0122 | 2 | 2 | 2 | 2 | 2 | Distance Tube, Return Spring to Headlamp | Non-Failsafe | |||||
| 14 | A04W0904 | 2 | 2 | 2 | 2 | 2 | Washer, Return Spring to Headlamp | Non-Failsafe | |||||
| 15 | A06W1207 | 6 | 6 | 6 | 6 | 6 | Washer, Return Spring to Headlamp | Non-Failsafe | |||||
| 16 | YUFN080P | 2 | 2 | 2 | 2 | 2 | Nut, Return Spring to Headlamp | Non-Failsafe | |||||
| 17 | 026B0388 | 1 | 1 | 1 | 1 | 1 | Spring, Headlamp Valve | Non-Failsafe | |||||
| 18 | 036B0118 | 1 | Spring, Headlamp Return | ||||||||||
| 19 | XUFS0416 | 1 | Screw, Return Spring | ||||||||||
| 20 | A05W1007 | 4 | Washer, Return Spring | ||||||||||
| L05W0000 | 4 | Washer, Return Spring | |||||||||||
| 21 | YUFN050F | 1 | Nut, Return Spring | ||||||||||
| 22 | 036B1658 | 1 | Rod, Operating | ||||||||||
| 23 | 036B6154 | 4 | Joint, Anti Rattle | ||||||||||
| 24 | A036B1657 | 2 | Link, Threaded | ||||||||||
| 25 | 026B0736 | 1 | 1 | 1 | 1 | 1 | Valve, Headlamp Operating | Non-Failsafe | |||||
| 26 | A026B0736 | 1 | Valve, Headlamp Operating | 1970 Federal Failsafe | |||||||||
| 27 | 036B6008 | 1 | Knob, Valve | ||||||||||
| 026B0039 | 1 | Bezel, Valve | |||||||||||
| 026B0129 | 1 | 1 | 1 | 1 | 1 | 'T' Piece | Upto 8729 | ||||||
| 026B0125 | 1 | 1 | 1 | 1 | 1 | Adaptor | Upto 8729 | ||||||
| 026B0136 | 1 | 1 | 1 | 1 | 1 | Non-Return Valve | Upto 8729 | ||||||
| 28 | J0019 | 1 | 1 | 'T' Piece | From 8730 | ||||||||
| 29 | 036B0136 | 1 | 1 | Non-Return Valve | From 8730 | ||||||||
| 036M6266 | 2 | 2 | 2 | 2 | 2 | Micro Switch | Non-Failsafe | ||||||
| J0017 | 1 | 1 | 1 | 1 | 1 | Sleeve | Non-Failsafe | ||||||
| 026B0387 | 1 | 1 | 1 | 1 | 1 | Pipe, Headlamp Valve | Non-Failsafe | ||||||
| 30 | 050M0124 | 2 | Micro Switch | 1970 Federal Failsaf | |||||||||
| 036J0135 | 1 | Elbow, Switch | 1970 Federal Failsaf | ||||||||||
| 036B1675 | 1 | Mounting Plate, Switch | 1970 Federal Failsaf | ||||||||||
| 036B1676 | 1 | Operatlng Shoe, Switch | 1970 Federal Failsaf | ||||||||||
| 036M0777 | 1 | Loom, Switch | 1970 Federal Failsaf | ||||||||||
| 036B6010 | 1 | Grommet, Loom | 1970 Federal Failsaf | ||||||||||
| 31 | 026B0131 | 1 | 1 | 1 | 1 | 1 | + | Pipe, 64 ins. long | |||||
| 32 | 026B0132 | 1 | 1 | 1 | 1 | 1 | + | Pipe, 61 ins. long | |||||
| 33 | 036B0381 | 1 | Pipe, 57 ins. long | ||||||||||
| 34 | 036B0380 | 1 | Pipe, 55 ins. long | ||||||||||
| 35 | 026B0133 | 1 | 1 | 1 | 1 | 1 | Pipe, 24 ins. long | ||||||
| 36 | 026B0130 | 1 | Pipe, 23 ins. long | ||||||||||
| 37 | J0017 | 8 | 8 | 8 | 8 | 5 | 3 | Sleeve | |||||
| 036B6009 | 1 | 'P' Clip, Pipes to Body | |||||||||||
| 036B6026 | 1 | Spire Screw, Pipes to Body | |||||||||||
| 036B6001 | 1 | Spire Nut, Pipes to Body | |||||||||||
| 036B6010 | 2 | Grommet, Pipes to Scuttle | |||||||||||
| 036B6011 | AR | Tape, Pipes Mounting |
