Ref. No. |  |  |  |  |  |  |  |  |  |  | |||
| Up to Unit 0745A, 0747A h *? 0772A, 0796A to 0847A, 01 *? to 0856A, 0455B, to 0466B, *? 115C. Up to 0146D, 0148D *? 0169D, 0171D, 0172D. Up *? 0104F. All nos inc. | |||||||||||||
| PC 1 | Thermostat | A075P6034SH | * | * | * | * | 1 | Ranco Switch | |||||
| PC 2 | Vacuum Switch | A075P6045SH | * | * | * | * | 1 | On/Off Valve | |||||
| PC 3 | Heat Sensing Unit | A075P6046SB | * | * | * | * | 1 | Vacuum Regulator | |||||
| PC 4 | Vacuum Actuator | A075P6039SL | * | * | * | * | 1 | Angled Link | |||||
| PC 6 | Vacuum Actuator | A075P6088F | * | * | * | * | 1 | Straight link | |||||
| PC 5 | Assembly Control Lever Panel | A075P6075F | * | * | * | * | 1 | ||||||
| Assembly Vacuum Hoses | A075P6076F | * | * | * | * | 1 | |||||||
| Motor | A075P6089F | * | * | * | * | 1 | Replaces motor assembly A075P6035S and A075P603 *? See Bulletin 1977/04. | ||||||
| Fan, RH (CCW) | A075P6090F | * | * | * | * | 1 | Replaces motor assembly A075P6035S and A075P603 *? See Bulletin 1977/04. | ||||||
| Fan, LH (CW) | A075P6091F | * | * | * | * | 1 | Replaces motor assembly A075P6035S and A075P603 *? See Bulletin 1977/04. | ||||||
| Adaptor Bracket | A075P6092F | * | * | * | * | 1 | Replaces motor assembly A075P6035S and A075P603 *? See Bulletin 1977/04. | ||||||
| Sleeve | A075P6093F | * | * | * | * | 1 | Replaces motor assembly A075P6035S and A075P603 *? See Bulletin 1977/04. | ||||||
| Rubber Mount | A075P6094F | * | * | * | * | 1 | Replaces motor assembly A075P6035S and A075P603 *? See Bulletin 1977/04. | ||||||
| Spacer - 5mm thick, 12.5 O/D, 5.0 I/D | A075P6095F | * | * | * | * | 1 | Replaces motor assembly A075P6035S and A075P603 *? See Bulletin 1977/04. | ||||||
| Elbow Connector, Vacuum | A075P6069F | * | * | * | * | 1 | Unequal bore | ||||||
| Elbow Connector, Vacuum | A075P6079F | * | * | * | * | 1 | Equal bore | ||||||
| Gasket,Motor Mounting | A075P6033C | * | * | * | * | 1 | |||||||
| Seal, transition Duct | A075P6038F | * | * | * | * | 1 | |||||||
| Expansion Valve | A075P6040SE | * | * | * | * | 1 | |||||||
| Gasket, Ballast Resistor | A075P6043SJ | * | * | * | * | 1 | |||||||
| Ballast Resistor | A075P6044SC | * | * | * | * | 1 | |||||||
| Heater matrix | A075P6029SE | * | * | * | * | 1 | |||||||
| Evaporator Matrix | A075P6074F | * | * | * | * | 1 | |||||||
