Esprit S1, S2, S2.2 PARTS MANUAL

Section MB -- Electrical -- Lamps


PLATE
Ref. No.
DESCRIPTION
PART NO.
REMARKS
Headlamp No. 1.B079M6004F* 2 Also Japan, For use on Single Motor Headlight Op. System.
Headlamp No. 1.A079M6042F* 2 For use on Single Motor Headlight Op. System.
Headlamp No. 1.A079M6021F* 2For use on Single Motor Headlight Op. System.
Headlamp No. 2. (Dip)B079M6003F* 2 Also Japan, For use on Single Motor Headlight Op. System.
Headlamp No. 2. (Dip)A079M6043F* 2 For use on Single Motor Headlight Op. System.
Headlamp No. 2. (Dip)A079M6022F* 2For use on Single Motor Headlight Op. System.
Headlamp Unit (Less Light Unit) No. 1.A079M6048F**2
Headlamp LJnlt (Less Light Unit) No. 2, DipA079M6053F**2
Headlamp Light Unit No. 1A079M6044F** 2 Also Japan
Headlamp Light Unit, No. 2, (Dip)A079M6045F** 2 Also Japan
Headlamp Light Unit, No. 1.A079M6040F** 2
Headlamp Light Unit, No. 2, (Dip)A079M6041F** 2
Headlamp Light Unit, No. 1.A079M6038F** 2
Headlamp Light Unit, No. 2, (Dip)A079M6039F** 2
Head lamp Assy, HalogenA079M6106K * 4 Also Japan
Headlamp Light Unit, HalogenA079M6104F * 4 Also Japan
Headlamp Assy, HalogenA079M6105K * 44Canada Fed.
Headlamp, Light Unit, HalogenA079M6103F * 44Canada Fed.
No.Plate Light Assy.A075M6025ZH**2
GasketA075M0256ZH**2
Rear Lamp Assy, RHA079M6000F* 11 Also Japan
Rear Lamp Assy, RHA079M6024F* 1
Rear Lamp Assy, LHA079M6001F* 11 Also Japan
Rear Lamp Assy, LHA079M6023F* 1
Lens, Reverse Light, RHA079M6078F* 1
Lens, Reverse Light, LHA079M6079F* 1
Lens, Stop/Tail Light, RHA079M6076F* 1
Lens, Stop/Tall Light, LHA079M6077F* 1
Lens, Flasher, Amber, RHA079M6080F* 11
Lens, Flasher, Amber, LHA079M6081F* 11
Lens, Flasher, Red, RHA079M6083F* 1
Lens, Flasher, Red, LHA079M6082F* 1
Rear Lamp Assy LHA079M6093F * 11 Also Japan
Rear Lamp Assy RHA079M6094F * 11 Also Japan, except Germany
Rear Lamp Assy RHA079M6095F * 1 Germany only.
Rear Lamp Assy, LHA079M6091F * 1
Rear Lamp Assy, RHA079M6092F * 1
Rear Lamp Earth LeadA079M4061F * 2
Rear Lamp Bridging LeadA079M4068F * 2
Side/Ind Lamp Assy, LHA075M6029WE** 11 Also Japan
Side/Ind Lamp Assy, RHA075M6028WL** 11 Also Japan
Side/Ind Lamp AssyA079M6032F** 2
Lens, Side/IndA075M6119Z** 22
Lens, Side/IndA079M6071F** 2
Interior LampA079M6008F* 1
Interior LampB075M6043F *1
Side Marker, Front, LHA079M6025F** 1Also Japan
Side Marker, Front, RHA079M6026F** 1Also Japan
Side Marker, Rear, LHA079M6027F** 1Also Japan
Side Marker, Rear, RHA079M6028F** 1Also Japan
Time Delay BuzzerA076M6005FC** 1
Control Illumlnafion LightA079M6036F* 2
Jumper Leads, Control Ilium. LightA079M4041F* 1
Repeater FlasherA075M6140W** 2Japan Only.
