 |  |  |  |  |  |  |  |  |  | Notes Bulletin Reference | |||
| 046B0001 | 1 | Body Shell | Up to 0541 | ||||||||||
| 046B0001A | 1 | Body Shell | From 0541 to 0644 | ||||||||||
| 054B0001 | 1 | Body Shell | |||||||||||
| 1 | 054B1800 | 1 | + | Body Shell (pre-24 in. headlamp centres) | Up to 2950 | ||||||||
| A054B1800 | 1 | + | Body Shell (24 in. headlamp centres) | From 0001P | |||||||||
| 054B1801 | 1 | + | Body Shell (pre-24 in. headlamp centres) | From 0645 to 2944 | |||||||||
| C054B1801 | 1 | + | Body Shell (24 in. headlamp centres) | From 0001Q | |||||||||
| A054B1801 | 1 | + | Body Shell (pre-24 in. headlamp centres) | From 1066 to 2061 | |||||||||
| D054B1801 | 1 | + | Body Shell (24 in. headlamp centres) | From 2607 to 2951 | |||||||||
| B054B1801 | 1 | + | Body Shell (24 in. headlamp centres - 65) | From Chassis No. 7001.03.0001R | |||||||||
| 046B0088 | 1 | 1 | Door Shell LH | ||||||||||
| 2 | 054B0089 | 1 | Door Shell LH | ||||||||||
| A054B0089 | 1 | 1 | Door Shell LH | ||||||||||
| 046B0089 | 1 | 1 | Door Shell RH | ||||||||||
| 3 | 054B0088 | 1 | Door Shell RH | ||||||||||
| A054B0088 | 1 | 1 | Door Shell RH | ||||||||||
| 046B0030 | 1 | Bonnet Lid | |||||||||||
| 4 | A046B0030 | 1 | 1 | 1 | Bonnet Lid | ||||||||
| 054B1829 | 1 | 1 | Reinforcing Strip | ||||||||||
| 036B6033 | 6 | 6 | Rivet Reinforcing Strip Mounting | ||||||||||
| 046B0040 | 1 | Engine Compartment Lid | |||||||||||
| 5 | A046B0040 | 1 | 1 | 1 | Engine Compartment Lid | ||||||||
| 054B0562 | 1 | 1 | Sealing - Front Stowage Compartment | ||||||||||
| 6 | 054B1387 | 1 | Blanking Panel | ||||||||||
| A054B1387 | 1 | Blanking Panel | |||||||||||
| 7 | 054B1386 | 1 | 1 | Blanking Panel | |||||||||
| PSTS1008 | 10 | 10 | Screw - Blanking Panels to Body | ||||||||||
| 036B6003 | 10 | 10 | Nut - Blanking Panels to Body | ||||||||||
| 046B0059 | 1 | 1 | Luggage Box | ||||||||||
| 8 | 054B0059 | 1 | 1 | Luggage Box | |||||||||
| 451A | 2 | 2 | 2 | 2 | Nut - Luggage Box to Chassis | ||||||||
| PUFS1016 | 2 | 2 | 2 | 2 | Screw - Luggage Box to Chassis | ||||||||
| A03W1606 | 2 | 2 | 2 | 2 | Washer - Luggage Box to Chassis | ||||||||
| W0060 | 2 | 2 | 2 | 2 | Spacer - Luggage Box to Chassis | ||||||||
| 9 | 046B2007 | 1 | 1 | 1 | 1 | Heat Shield | |||||||
| 046B2005 | 1 | 1 | 1 | 1 | Heat Shield | ||||||||
| 435 | 4 | 4 | 4 | 4 | Rivet - Heat Shield to Luggage Box | ||||||||
| AUFN030F | 4 | 4 | 4 | 4 | Nut - Heat Shield to Luggage Box | ||||||||
| A03W0806 | 4 | 4 | 4 | 4 | Washer - Heat Shield to Luggage Box | ||||||||
| 046B0241 | 1 | 1 | Cover - Battery | ||||||||||
| MUFS1016 | 2 | 2 | Screw - Battery Cover | ||||||||||
| 046B0029 | Replaced by 046B0029A | ||||||||||||
| 10 | 046B0029A | 1 | 1 | 1 | 1 | Windscreen | |||||||
| 054B0029 | 1 | 1 | 1 | 1 | Windscreen - Shaded - Optional | ||||||||
| 11 | 046B0549 | 1 | 1 | 1 | Weatherstrip - Windscreen | Up to Chassis No. ? | |||||||
| 046B0549 | 1 | Weatherstrip - Windscreen | Up To Chassis No. 2951 | ||||||||||
| A050B6182 | 1 | Mastic Sealer | From Chassis No. 7001.03.0001R | ||||||||||
| A050B6181 | 1 | Mastic Sealer | From Chassis No. 7001.03.0001R | ||||||||||
| A054B6124 | 2 | Mounting Blocks | From Chassis No. 7001.03.0001R | ||||||||||
| 12 | 046B6002 | 1 | 1 | 1 | Filler Strip (150 in.) | ||||||||
| 046B6002 | 1 | Filler Strip | Up to Chassis No. 2951 | ||||||||||
| A054B6118 | 1 | Finisher - Top | From Chassis No. 7001.03.0001R | ||||||||||
| A054B6119 | 1 | Finisher - Bottom | From Chassis No. 7001.03.0001R | ||||||||||
| A054B6120 | 1 | Finisher - LH | From Chassis No. 7001.03.0001R | ||||||||||
| A054B6126 | 1 | Finisher - RH | From Chassis No. 7001.03.0001R | ||||||||||
| A054B6125 | 2 | Corner Clip - Top | From Chassis No. 7001.03.0001R | ||||||||||
| A050B6183 ? | 2 | Corner Clip - Bottom | From Chassis No. 7001.03.0001R | ||||||||||
| A054B6121 | 1 | Filler - Top Internal | From Chassis No. 7001.03.0001R | ||||||||||
| A054B6122 | 1 | Filler - Bottom Internal | From Chassis No. 7001.03.0001R | ||||||||||
| A054B6123 | 2 | Filler - Side Internal | From Chassis No. 7001.03.0001R | ||||||||||
| 13 | 046B0349 | 1 | 1 | 1 | 1 | Rear Screen | |||||||
| B046B0349 | 1 | 1 | 1 | 1 | Rear Screen Shaded Optional | ||||||||
| 046B6004 | Replaced by 054B1769 | ||||||||||||
| 14 | 054B1769 | 1 | 1 | 1 | 1 | Weatherstrip - Rear Screen | |||||||
| 15 | 046B6003 | 1 | 1 | 1 | 1 | Filler Strip - Rear Screen | |||||||
| 046B6039 | Replaced by 036B6031 | ||||||||||||
| 16 | 036B6031 | 1 | 1 | 1 | 1 | Internal Rear View Mirror | |||||||
| 036B6108 | 1 | 1 | Sunvisor | ||||||||||
| 17 | 054B1720 | 2 | 2 | Sunvisor |
