 |  |  |  |  |  |  |  | Notes Bulletin Reference | |||
| 1 | B050A0701 | 1 | Chassis Assembly | ||||||||
| 2 | 036A0004 | 1 | Cross Brace | ||||||||
| KUFS0616 | 2 | Screw, Cross Brace | |||||||||
| 3 | 036A0252 | 2 | Bush, Cross Brace | ||||||||
| YUFN060F | 2 | Nut, Cross Brace | |||||||||
| 4 | A050A0266 | 2 | Fulcrum Pin | ||||||||
| 5 | 026A0219 | 4 | Cupwasher | ||||||||
| 6 | 050A0060 | 1 | Rear Strut Brace | ||||||||
| XUFS0724 | 2 | Bolt, Rear Strut Brace | |||||||||
| A07W1406 | 2 | Washer, Rear Strut Brace | |||||||||
| 036B0685 | 2 | Washer, Rear Strut Brace | |||||||||
| 7 | D026P0002 | 1 | Gearbox Mounting | ||||||||
| 8 | 050B1000 | 2 | Spacer, Gearbox Mounting | ||||||||
| XUFS0508 | 4 | Screw, Gearbox Mounting | |||||||||
| L05W0000 | 4 | Washer, Gearbox Mounting | |||||||||
| 9 | A026R0007 | 1 | Torque Rod, LH | ||||||||
| 10 | A026R0006 | 1 | Torque Rod, RH | ||||||||
| 11 | 026R6001 | 4 | Bush, Torque Rods | ||||||||
| 12 | 036C6001 | 4 | Washer, Torque Rods | ||||||||
| 13 | 036C6000 | 2 | Washer, Torque Rods | ||||||||
| 14 | LUFN050F | 2 | Nut, Torque Rods | ||||||||
| 026D0703 | 2 | Mounting, Top - Differential | Upto 50/1549 | ||||||||
| A036R6000 | 2 | Mounting, Top - Differential | From 50/1550 | ||||||||
| 050R0027 | 2 | Bolt, Mounting to Differential | |||||||||
| YUFN060F | 2 | Nut, Mounting to Differential | |||||||||
| XUFS0512 | 4 | Bolt, Mounting to Chassis | |||||||||
| L05W0000 | 4 | Washer, Mounting to Chassis | |||||||||
| 15 | A036H0060 | AR | Shim, Steering Unit Mounting | ||||||||
| 15 | A036H0061 | AR | Shim, Steering Unit Mounting | ||||||||
| A036R0033 | 1 | Bracket - Differential Stiffening | |||||||||
| XUCB0528 | 2 | Bolt - Bracket Securing | |||||||||
| None | AR | Loctite 'AV' - Bolts |
