![]() | ![]() | ![]() | ![]() | ![]() | ![]() | ![]() | ![]() | Notes Bulletin Reference | |||
| 050M6000 | 1 | Windscreen Wiper Motor (replaced by 050M6111) | |||||||||
| 050M600A | 1 | Windscreen Wiper Motor (replaced by 050M6111) | |||||||||
| 1 | 050M6111 | 1 | Windscreen Wiper Motor | ||||||||
| XUFS0416 | 2 | Screw - Windscreen Wiper Motot Mounting | |||||||||
| 2 | 046M6155 | 1 | Mounting Bracket | ||||||||
| 3 | 050M0010 | 1 | + | Bundy - Motor to Wheelbox | |||||||
| 050M0003 | 1 | + | Bundy - Motor to Wheelbox | ||||||||
| 4 | 050M0011 | 1 | Bundy - Wheelbox to Wheelbox | ||||||||
| 5 | 026M0012 | 1 | Bundy - Wheelbox to End | ||||||||
| 6 | 036M6015 | 1 | Grommet - Bundy to Bulkhead | ||||||||
| 7 | 036M6151 | 2 | Wheelbox | ||||||||
| 050M6004 | 1 | + | Windscreen Wiper Arm RH | Upto ? | |||||||
| 050M6004A | 1 | +- | Windscreen Wiper Arm RH | Upto ? | |||||||
| 8 | 050M6106 | 1 | + | Windscreen Wiper Arm LH | From ? | ||||||
| A050M6190 | 1 | + | Windscreen Wiper Arm RH | Upto ? | |||||||
| 050M6003A | 1 | + | Windscreen Wiper Arm RH | Upto ? | |||||||
| 050M6103 | 1 | + | Windscreen Wiper Arm LH | From ? | |||||||
| 9 | 050M6105 | 2 | 2 | Windscreen Wiper Blade | Upto ? | ||||||
| 050M6005 | 2 | Windscreen Wiper Blade | From ? | ||||||||
| 10 | 050M6104 | 1 | Windscreen Wiper Arm (straight) Driver's Side | From ? | |||||||
| A050M6189 | 1 | Windscreen Wiper Arm (straight) | Upto ? | ||||||||
| 050M6002A | 1 | Windscreen Wiper Arm (straight) (satin) | From ? to ? | ||||||||
| 11 | 050B6136 | 1 | Spacer | ||||||||
| 12 | 050B077 | 1 | Washer Unit | Upto ? | |||||||
| 050B6000 | 1 | Washer Unit | From ? | ||||||||
| 13 | 050B6001 | 1 | Washer Reservoir | ||||||||
| 14 | 036M6085 | 2 | Jet | ||||||||
| 050M6005 | 1 | 1 | 1 | Washer Unit | |||||||
| 15 | 036M6159 | 1 | 1 | 1 | Washer Unit | ||||||
| 036M6260 | 1 | 1 | 1 | Washer Pump | |||||||
| 050M6003 | 1 | Tube - Bottle to 'T' Piece | |||||||||
| 050M6004 | 2 | Tube - 'T' Piece to Jet | |||||||||
| 050M6002 | 1 | 'T' Piece |
